CT Direct Ex Heater

ELECTRICAL DIRECT HEATER – MODEL CT-(*)A

Description

Application

Direct-heaters for Hazardous locations, designed for direct mounting onto e.g. manifolds etc.

Freeze protection
Anti-condensation
Temperature maintenance

Features and Advantages

Self-limiting heating elements
Small dimensions
No moving parts, no maintenance required, therefore long lifetime
Suitable for T4 and T3 classifications
Can be used for 110/240 VAC/DC

Remarks

All Cameo Heaters are designed around self-limiting heating elements. These semi-conductor elements are saving power consumption. Our Cameo Direct-heaters are designed to heat the installed equipment. If properly selected for freeze protection, no thermostat will be needed.

When required in other applications, e.g. analyzers, it is normal practice to use our Direct-heaters
in combination with our Fix-Therm96 thermostats (range from 10°C up to 135°C) or our FixTherm Inline Thermostat(range from 10°C up to 60°C).

Range

CT-1A T3 ca. 115 °C Surface temperature* 250-25 Wat

CT-2A T4 ca. 105 °C Surface temperature* 250-25 Wat

CT-3A T4 ca. 90 °C Surface temperature* 250-25 Wat

CT-4A T4 ca. 70 °C Surface temperature* 250-25 Wat

* these temperatures are measured at 20 °C ambient temperature.

Technical data

Power 250-25 Watt

Electrical cable 3 x 1 sqmm

Material cable braided silicone, optional: non-braided cable

Standard length ca. 1 mtr. Other lengths optional

Overall dimensions 88 x 70 x 35 mm (LxWxH)

Weight ca. 550 g.

Material black anodized aluminium

Protection class II 2G Ex d IIC T4 or T3

II 2D Ex tD A21 IP66 T 135°C or T200 °C

Certification KEMA 01ATEX2124X and IECEx DEK 11.0017

IP degree IP 66

Voltage AC/DC 110/240

Ambient temp. range – 60 °C … + 90 °C
